JT-SSJ II-E Household Combustible Gas Detector

Detected Gas:propane

Signal Output:Wireless Valve Actuation

Dimensions:Ф87mm x 46mm

Optional Equipment:Emergency Shut-Off Valve

Executive Standard:GB 15322.2-2019

Product Details
Specs & Params
Related Products

Product Description:

The JT-SSJ II-E Type Combustible Gas Detector is designed in compliance with the national standard GB15322.2-2019. It can detect the on-site gas concentration in real time and determine whether the gas concentration exceeds the alarm threshold. If the alarm threshold is exceeded, the device will emit an audible and visual alarm signal, and link with the emergency shut-off valve to cut off the gas supply. The IoT-enabled model (optional) can push alarm information via WeChat, platforms, and APPs. This detector is suitable for leakage monitoring of indoor natural gas pipelines in households.


Product Features:

※ Equipped with LED service life indication.

※ Features an alarm mute function.

※ Concentration and fault alarm indicators use high-brightness concentrated LEDs of different colors.

※ Adopts high-quality gas-sensing elements, with stable performance, high sensitivity, excellent anti-toxicity, and strong anti-interference capability.

※ High performance, low power consumption, simple operation, and easy maintenance.

※ IoT-enabled, with remote alarm information push via WeChat, platforms, and APPs (optional).

※ Wireless valve activation reduces on-site wiring difficulty and enables flexible installation.

Rated VoltageAC 220V±15%
Signal OutputWireless Valve Actuation
Alarm Set Value8% LEL
Detected GasMethane
Measuring Range0-16% LEL
Error±3% LEL
Alarm MethodAudible and Visual Alarm
Sampling MethodNatural Diffusion
Communication Method (Optional)4G-CAT1
Operating Temperature-10°C~55°C
Operating Humidity≤93%RH (No Condensation)
Overall DimensionsФ87mm x 46mm
MaterialABS
Installation MethodPlug-in
Executive StandardGB 15322.2-2019
Optional EquipmentEmergency Shut-off Valve
